32 Bit Microprocessor Trainer is 32-bit Microprocessor Training System is based on the Intel 386Ex microcomputer. The i386EX is a high performance, 32-bit, single-chip microcomputer that is software compatible with the Intel 80386 family of microprocessors. DOS compatibility allows development in a familiar environment with a wide range of tools. The application can then be tested through the console serial port. Borland C compiler IDE enables environment for east development of programs/applications. PC software is provided with the training system to upload programs and to execute the programs on the training system.
Specification
- EXTERNAL I/O INTERFACE:
- 16X4 Character LCD
- 4X 7-Segment Displays
- 8-Bit Monitor LEDs
- 4X4 Matrix Keypad with 5-way joystick
- 8 bit A/D converter
- 8 bit D/A Converter.
- 8 bit Dip-Switches.
Technical data
- MOTHERBOARD:
- 25Mhz Intel 386Ex Processor
- XDOS (PC DOS 3.3 Compatible) 415K Flash
- 34 Digital I/O lines
- 1 RS-232 Port with USB UART interface
- PC Console Port for program uploading / execution
- 3 PC Compatible Counter/Timer Channels
- Watchdog Timer
- Programmable Hardware Clock Generator
- Selected PC BIOS Functions
- Full Address/Data Expansion Bus
Dimensions and weight
LxWxH:350 x 350 x 100
Weight:2.5kg
