Torsion is the twisting or wrenching of a body by the exertion of forces tending to turn one end or part about a longitudinal axis while the other is held fast or turned in the opposite direction.
Torsion is a typical load to which components are subjected. The resultant stresses and deformations can lead to failure of the component. A number of different factors play a role in this, including the material, the cross-section of the bar, the clamping length and the method of bearing support.
Specification
- Aluminum Frame.
- Graduated Disk.
- Chucks for holding for bars.
- Weights for loading purpose.
Technical data
- Torsion bars:
- Material: aluminium, steel, brass, copper.
- Ø 10mm: l=50 - 640mm (aluminium).
- ØXL:10x50mm/10x340mm (aluminium, steel, copper, brass).
- Diameter with L=50/340mm: Ø5 - 12mm (steel).
- Graduated Disk:
- 0 to 360o with 1o resolution.
- Weights:
- 1x 100g (hanger).
- 1x 100g.
- 1x 400g.
- 1x 500g.
- 1x 900g.
Dimensions and weight
LxWxH:1000 X 300 X 400
Weight:18 kg
