Piston pumps used to move liquids or compress gases. They can operate over a wide range of pressures.
High pressure operation can be attained without a sturdy consequence on flow rate. Apparatus contains
LCD display.
Optional Software is available for Data Acquisition and Control Function.
Specification
- Closed water circuit.
- Transparent water container.
- Valve for adjusting the flow rate.
- Sensors for pressure at outlet and in the
cylinder of the pump and flow rate.
- Working behaviour of a piston pump.
Technical data
- Piston Pump: 2LPM.
- Gear Transmission Ratio: 1:7.5.
- Two transparent Tank.
- Tank 1: 10L.
- Tank 2: 3L.
- LCD display.
- 230V AC 50Hz.
Dimensions and weight
LxWxH:600 X 450 X 750
Weight:40 kg
